| 1st tank specification of Ultrasonic Cleaning Equipment | |
| Function | Ultrasonic cleaning + Filter |
| Ultrasonic Frequency | 28kHz |
| Tank Material | SUS 304 |
| Inner tank dimension | 550*400*350mm |
| Tank Capacity | 77L |
| Transducer | 24pcs |
| Ultrasonic Power | 1200W |
| Heating Power | 3000W |
| Time setting of Ultrasonic | 0~99 hours |
| Temperature setting | Room temperature ~ 95°C adjustable |
| Genrator | 1 set |
| Filtration cycle system | 1 set, connect with 1st tank |
| 2nd tank specification of Ultrasonic Cleaning Equipment | |
| Function | Ultrasonic cleaning |
| Ultrasonic Frequency | 28kHz |
| Tank Material | SUS 304 |
| Inner tank dimension | 550*400*350mm |
| Tank Capacity | 77L |
| Transducer | 24pcs |
| Ultrasonic Power | 1200W |
| Heating Power | 3000W |
| Time setting of Ultrasonic | 0~99 hours |
| Temperature setting | Room temperature ~ 95°C adjustable |
| Genrator | 1 set |
| 3rd tank specification of Ultrasonic Cleaning Equipment | |
| Function | Hot air drying tank |
| Inner tank dimension | 550*400*350mm |
| Turbines power | 750W |
| Dryer power | 3000W |
| Temperature setting | 20~150℃ adjustable |
| General of Ultrasonic Cleaning Equipment | |
| Quantity | 1pcs |
| Power supply | 380V / 50Hz |
| Gross weight(no lifting) | 350KG |
| Gross weight(with lifting) | 450KG |
| Overall size(no lifting) | 2300*1100*1100mm |
| Overall size(with lifting) | 3000*1100*1900mm |
| Production time | 25 working days |
