Plastic Mold Ultrasonic Cleaner for Removing Polypropylene Dust, Oil, and Dirt
This specialized ultrasonic cleaning system effectively removes polypropylene dust, oil, and dirt from plastic molds using advanced ultrasonic technology.
How Ultrasonic Cleaning Differs
Ultrasonic energy generates controlled, high-magnitude pressure fluctuations in liquids that produce consistent, high-level cleanliness in minimal time. Unlike conventional methods, ultrasonic cleaning penetrates minute crevices that other cleaning techniques cannot reach.
Plastic Tool Model Cleaning Procedure
- Fill the tank with appropriate cleaning chemistry and activate heating
- Ensure the tool model doesn't trap air and all surfaces are properly wetted
- Activate ultrasonic energy by turning the system on
- Remove cleaned tool model when cycle completes and ensure complete drainage
- Thoroughly rinse all surfaces with clean water
- Dry tool model using evaporation, air-drying, or forced hot air
Plastic Mold Cleaning Process
Recommended precision cleaning process using Skymen Model JP-720ST ultrasonic cleaning unit:
| Process Stage |
Ultrasonic Frequency |
Handling |
Temperature (°C) |
Time (minutes) |
| Wash |
40KHz |
Basket |
60 |
5 |
| Rinse |
N/A |
Basket |
Warm |
N/A |
| Dry |
N/A |
Basket |
Ambient |
Until dry |
This complete process effectively removes all polypropylene dust, oil, and dirt from plastic molds, significantly saving labor and time.
Technical Specifications
| Model |
JP-720ST (digital, power adjustable) |
| Tank Size |
1000×600×600mm |
| Wood Case Packing |
1300×900×1100mm |
| Ultrasonic Power |
1440W~3600W |
| Heating Power |
12KW |
| Timer |
1~99min adjustable |
| Heater |
20~80°C adjustable |
| Frequency |
40,000Hz |
| Tank Capacity |
360L With Roller |
| Gross Weight |
280kg |
| Power Adjustable |
40%-100% |
Packing and Delivery
Custom Solutions Available
If our standard tank size doesn't meet your requirements, we offer larger ultrasonic cleaners and can design and produce custom ultrasonic cleaning machines with special functions.
Skymen Company Advantages
With 10 years of industry experience, we supply ultrasonic cleaning machines to customers worldwide. We welcome distributors for mutually beneficial cooperation.
Certifications and Approvals
Our company holds ISO certification, High Tech Company status, CE, RoHS, FCC, and National Medical Instrument Approval.
