20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane

20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane
20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane

Large Image :  20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane

Product Details:
Place of Origin: China
Brand Name: SKYMEN
Certification: CE, RoHs, FCC
Model Number: JP-11512ST
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: wooden case
Delivery Time: In Stock
Supply Ability: 100 pcs per month

20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane

Description
Cleaning Way: Automatic Chamber Dimension: 800*120*120cm
Frequency: 28KHz Lift For Tower: Available
Tower Diameter: Below 1.6m Heating Power: 72000W
Ultrasonic Power: 75600W Crane: Available
High Light:

20000L Ultrasonic Washing Machine

,

Ultrasonic Washing Machine 28KHz

,

Cylindrical Ultrasonic Cleaning Equipments

20000L Ultrasonic Washing Machine 28KHz Cylindrical Heat Exchanger with Crane


Ultrasonic Cleaning Machine For Heat Exchanger

The traditional method of washing the heat exchanger is to use a high-pressure spray water gun. The cleaning cost is low, but there are also obvious disadvantages. If the water pressure is too large, the pipeline may be damaged, and the heat exchange tube cannot be cleaned inside, and there is still residual dirt. . Ultrasonic cleaning equipment can solve this problem well. Using the cavitation of ultrasonic waves in water, the dirt attached to the surface of the heat exchange tube is loosened, peeled off in water, and the internal pipes and gaps are effectively cleaned.

The most suitable cleaning temperature for the water cleaning solution is 50-60 ° C. Especially in the case of cold weather, if the temperature of the cleaning solution is low, the cavitation effect is poor, and the cleaning effect is also poor. Therefore, some washing machines are wound around the heating cylinder to heat the heating wire for temperature control. When the temperature rises, cavitation is easy to occur, so the cleaning effect is good. When the temperature continues to rise, the gas pressure in the bubble increases, causing the impact sound pressure to drop, reflecting the multiplication of the two factors.




Detailed Specification of this machine:

1
Model
JP-11512ST
2
Parameter

Function
Ultrasonic cleaning
Ultrasonic Frequency
28/40kHz (other frequency can be customized)
Tank Material
SUS 304 (SUS 316 can be customized)
Thickness of tank 3mm
Inner tank dimension
8000*1600*1600mm
Tank Capacity
20480L
Transducer
1512pcs
Ultrasonic Power
75600W
Heating Power
72000W
Time setting of Ultrasonic
0~99 hours
Temperature setting
Room temperature ~ 95°C adjustable
Drain value
Available
Water inlet/outlet
Available
Generator
42 sets
Generator power control 1800W
Generator shelf Available
Basket Available
Basket load
8000KG
3
Packing
Overall size
870*210*250cm
Packing size
880*220*280cm
Packing detail By wooden case(No logs, free of fumigation)
N.W/G.W
9000KG/9500KG
4 Power supply 380V 3 phase; 220V 3 pahse; 415V; 600V
5
Warranty
1 year warranty for spare parts, all life technical support
6
Certificate
CE, RoHS; FCC, REACH
7
Lead time
20~30 working days after deposit
7 Optional functions Filtration cycle system Available; capture dirty water, recycle clean water
Lifting system for basket Available; take the basket up and down
Dunking system Available; Speed up cleaning
Bubbling Available; need to connect air compressor
Electrolysis Available; For cleaning more complex structure mold
Cooling system Available; To cool down inflammable and explosive
Constant temperature Available;
Roller barrel Available; for clean coins and big quantity parts
Anti-explosion electric box Available;
Crane Available;
Deionized(DI) water Available;
Double/Multi frequency Available; 28/40/20/68/80/132KHz
Other funtions Negotiate via email



20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 0




Other size and capacity for reference:

20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 1


20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 2


20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 3


20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 4


20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 5


20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 6


20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 7


20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 8


20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 9


20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 10


20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 11


20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 12


Product show:

20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 1320000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 1420000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 1520000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 1620000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 1720000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 1820000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 19


Cleaning effect show:

20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 20

20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 21


Skymen Cleaning Equipment Shenzhen CO., Ltd.

20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 22

20000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 2320000L Ultrasonic Washing Machine 28KHz Cylindrical With Crane 24


The role of the Crane:
When you clean the items, it is more difficult to put the items in or out of the washing tank. The crane can solve this difficulty very well, just start the button, the object will automatically immerse and lift the sink, very labor-saving.
