Product Details:
Document: Product Brochure PDF
Payment & Shipping Terms:
Minimum Order Quantity: 1

New Arrivals Large Double Tanks Industrial Ultrasonic Cleaner with Filtration and Rinsing System for Autoparts

Description
Model No.: JP-2036G Ultrasonic Frequency: 28/40 KHz
Material: Stainless Steel SUS304 Tank Capacity: 53L For Each
Timer: 1~99hours Adjustable Heater: 20°C To 95°C Adjustable
Degas: Yes Semiwave: Yes
Power Supply: AC 100 ~ 120V, 50 / 60Hz, AC 220 ~ 240V, 50 / 60 Hz Ultrasonic Power: 0-900 W
Heating Power: 1500 W Tank Size: 500*350*300mm ( L X W X H )
Unit Size: 1360*1000*750mm ( L X W X H ) Package Size: 1420*1060*870mm(L*W*H)
G.W.: 195kg

New Arrivals Large Double Tanks Industrial Ultrasonic Cleaner with Filtration and Rinsing System for Autoparts
1 Model No. JP-2036G
2 Image New Arrivals Large Double Tanks Industrial Ultrasonic Cleaner with Filtration and Rinsing System for Autoparts
3 Ultrasonic model Ultrasonic Frequency 28/40 kHz
Material Stainless Steel SUS304
Tank Capacity 53L for each
Timer 1~99hours adjustable
Heater 20°C to 95°C adjustable
Degas  Yes
Semiwave Yes
Power Supply AC 100 ~ 120V, 50 / 60Hz
AC 220 ~ 240V, 50 / 60 Hz
Ultrasonic Power 0-900 W
Heating Power 1500 W
Basket& cover Standard equiped
4 Packing Tank Size 500*350*300mm ( L x W x H )
Unit Size 1360*1000*750mm  ( L x W x H )
Package Size 1420*1060*870mm(L*W*H)
G.W. 195kg
Warranty 1 year
5 Features. 1. stainless steel tank has resistance to wear and long work life.
2. with filtration and rinsing stsyem,
3. with stainless steel basket and cover.
4. use just tab water, or industrial alcohol and solvent cleaner for more higher cleaning requirement
5.ultrasonic cleaning solutions penetrate virtually any soil type including: oils, residues, solvents, pastes and chemicals and other contaminants are safely lifted and dispersed, leaving a surface appearance that is clean and free of particulate; even in crevasses and internal bores.
6 Application. medical industry, electronic factory, molding factory, car workshop, diesel workshop, car industry, scientific laboratory, university lab, hardware tools shop.
7 Certificates CE/ROHS/FCC/PSE/ISO9001


Features:
Adjustable ultrasonic power
Original BLT type transducer
SUS 304 stainless steel tank
Adaptable for continuous operation
Adjustable thermo controller
Adjustable ultrasonic power
With separate control ultrasonic electronic generator
Sweep mode control available
Digital timer & heating control
Boost mode& oil skimmer upon clients requirement
Pressure pump and filter system are available


Application:
-Scientific Labs:Eyeglass Frames;Lab Glassware;Optical&Contact Lenses;Pipettesscientific Instruments;Test tubes
-Industrial Manufacturing:Assemblies;Gears;Metal&Plastic Parts;Precision Bearings
-Electronic manufacturing:Capacitors;Ceramic Substrates;PC Boards;Packaging Components;Quartz Crystals
-Medical and Dental Lab:Burs;Blood Oxygenators;Dental Instruments;Syringe Parts;Surgical Instruments
-Jewelry Manufacturing:Chains;Charms;Coins;Intricate Settings;Precious Metals&Gemstones;Watches


How ultrasonic cleaner works:

Electrical energy is converted into mechanical vibrations thanks to special elaborated transducers.These vibrations are transferred into the fluid through the walls of stainless steel.This creates tiny microscopic vacuum bubbles, which cause consecutive implosions (cavitation).The high-energy jets that are thus created can efficiently remove dirt from surfaces an materials placed in the cleaning bath.

An ultrasonic cleaner in your kitchen will save time and reduce effort while providing a safe solution for your kitcheware. With the help of oil remove detergent ,the ultrasonic cleaner could fast and efficient take the oil ,polish the kitcheware.
when using an ultrasonic cleaner on glassware, plasticware, and your lab instruments. Whether you are cleaning oven trays, pans. studies have shown that it can be up to 30 times faster while delivering thoroughly clean results.

New Arrivals Large Double Tanks Industrial Ultrasonic Cleaner with Filtration and Rinsing System for AutopartsNew Arrivals Large Double Tanks Industrial Ultrasonic Cleaner with Filtration and Rinsing System for AutopartsNew Arrivals Large Double Tanks Industrial Ultrasonic Cleaner with Filtration and Rinsing System for AutopartsNew Arrivals Large Double Tanks Industrial Ultrasonic Cleaner with Filtration and Rinsing System for Autoparts

Company profile
Here are the Skymen company.You can know more about us with the details.

New Arrivals Large Double Tanks Industrial Ultrasonic Cleaner with Filtration and Rinsing System for AutopartsNew Arrivals Large Double Tanks Industrial Ultrasonic Cleaner with Filtration and Rinsing System for Autoparts

FAQ:
Buying Guides

 1. Choose suitable tank size based on cleaning objects, size can be customized

 2. Choose suitable frequency, 40kHz for commen use and 28kHz for heavy duty oil removal

 3. Choose tank meterial based on solvent, SUS304 or SUS316L

 4. Other function optional,

    Ultrasonic cleaning tank + Ultrasonic Rinsing tank

    Ultrasonic cleaning tank + Air agitation Rinsing tank

    Ultrasonic cleaning tank + Water Rinsing tank

    Ultrasonic cleaning tank + Hot air drying tank

    Oil filtertation system: detergent recycle use to save much cost
