36gallon Jp-360st Industrial Ultrasonic Cleaner Machine

36gallon Jp-360st Industrial Ultrasonic Cleaner Machine
36gallon Jp-360st Industrial Ultrasonic Cleaner Machine 36gallon Jp-360st Industrial Ultrasonic Cleaner Machine 36gallon Jp-360st Industrial Ultrasonic Cleaner Machine 36gallon Jp-360st Industrial Ultrasonic Cleaner Machine

Large Image :  36gallon Jp-360st Industrial Ultrasonic Cleaner Machine

Product Details:
Document: Product Brochure PDF
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 1324
Contact Now

36gallon Jp-360st Industrial Ultrasonic Cleaner Machine

Description
Tank Size: 600*500*450 Mm Tank Capacity: 135 L
Transducers: 36 Ultrasonic Power: 1800 W
Heating Power: 4500 W Frequency: 28K OR 40Khz
Tank Material: 304 Stainless Steel Tank Thickness: 2.5 Mm
Timer: 1s-99 Hours Heater: 20-95°C
Drain Valve: 1 Inch Machine Voltage: AC220-240V/60Hz; AC380-400V/50Hz ; 3 Phase
Generator Voltage: 2 Sets Basket & Lid: Yes
With Castor: Yes
Highlight:

36gallon industrial ultrasonic cleaner

,

JP-360ST ultrasonic cleaning machine

,

large capacity ultrasonic cleaner

36 Gallon JP-360ST Industrial Ultrasonic Cleaner Machine
Stainless Steel 304 Professional Industrial Aircraft Maintenance Ultrasonic Cleaning Machine
JP-360ST Industrial Ultrasonic Cleaner Machine
Technical Specifications
Model JP-360ST JP-480ST JP-600ST JP-720ST
Tank Size (MM) 600×500×450 700×500×500 800×600×550 1000×600×600
Tank Capacity (L) 135 175 264 360
Transducers 36 48 60 72
Ultrasonic Power (W) 1800 2400 3000 3600
Heating Power (W) 4500 6000 6000 9000
Frequency 28K OR 40Khz
Tank Material 304 Stainless Steel
Tank Thickness 2.5 mm
Timer 1s-99 hours
Heater 20-95°C
Drain Valve 1 inch
Basket & Lid Yes
Machine Voltage AC220-240V/60Hz; AC380-400V/50Hz ; 3 phase
Generator Voltage 2 sets
Features With castor
Packing Carton
Special Features
  • Stainless Steel Construction ensures solidness and durability
  • High efficiency transducer
  • All Components are Easily Accessed for Maintenance Operations
  • Fiberglass Control Enclosure Provides Ease of Operation while Eliminating Potential Corrosion
  • Digital Ultrasonic Timer Included as Standard Equipment
  • Filtration system / customized size available
How Ultrasonic Cleaning Works
Electrical energy is converted into mechanical vibrations thanks to special elaborated transducers. These vibrations are transferred into the fluid through the walls of stainless steel. This creates tiny microscopic vacuum bubbles, which cause consecutive implosions (cavitation). The high-energy jets that are thus created can efficiently remove dirt from surfaces and materials placed in the cleaning bath.
Industrial Applications
An industrial ultrasonic cleaner plays an important role in refurbishing equipment. The refurbishing process includes taking the equipment apart; cleaning the unit as well as any parts that can be salvaged; replacing, repairing or upgrading damaged components; reassembling the equipment; and then doing touch ups or cosmetic enhancements. Ultrasonic cleaning is ideal for cleaning these parts prior to reassembly, thoroughly removing any oils, coolants, or sludge build up.
Ultrasonic cleaning is faster than conventional aqueous cleaning without damaging parts. Specifically, ultrasonic pre-treatment of parts allows for batch processing and removes polishing compounds without staining or reducing adhesion in parts to be electro-plated. Ultrasonic cleaning is perfect for degreasing tools and parts without manual scrubbing, capable of handling jobs that require both firm and gentle cleaning.
Before and After Results
Ultrasonic cleaning before and after comparison Industrial parts cleaning demonstration Cleaned components after ultrasonic processing
Frequently Asked Questions
How long do I need to clean my components for?
Cleaning time varies depending on the performance of your ultrasonic bath and the level of contamination present. Different conditions (temperature, ultrasonic power, detergent and detergent dose) will all have an effect on the length of time required to clean a component.
How much can I load into my ultrasonic cleaner?
The more instruments placed into an ultrasonic bath, the less effective the cleaning cycle will be. It is not advisable to place instruments in the basket so that they overlap as a more effective clean will be generated if all surface areas are openly exposed to the cleaning solution. However, filling a basket so that there is clear space between instruments should lead to an effective cleaning cycle.
Should the lid be on my ultrasonic cleaner when in operation?
The lid should be kept on the ultrasonic cleaner while in operation. The lid protects the operator and in medical applications, patients as well. It prevents aerosols generated during the cavitation process from dispersing and contaminating the reprocessing environment. In addition, the lid reduces noise levels created during the ultrasonic cycle and helps maintain the heat of the cleaning fluid in the tank.
