Product Details:
|
| Model: | JP-1500P | Cleaning Method: | High Pressure Spraying |
|---|---|---|---|
| Basket Diameter: | 1500mm | Work Space Height: | 500mm |
| Basket Load-bearing: | 400KG(can Be Customized) | Rotating Speed: | 10~50R/MIN |
| Water Pump Power: | 3KW | Sub-Tank Capacity: | 200L |
| Basket Rotation Drive: | Motor/0.55kw | Heating Power: | 9KW |
The Spraying Cleaning Machine is an industrial cleaning machine designed for the efficient and thorough cleaning of cylinder heads and other engine parts. It utilizes high pressure spraying to remove stubborn dirt and grime from the surface of the parts, leaving them clean and ready for use.
The Spraying Cleaning Machine is specifically designed for the cleaning of cylinder heads and other engine parts. With a basket diameter of 1500mm, it can easily accommodate multiple parts at once, increasing efficiency and reducing cleaning time.
The tank of the Spraying Cleaning Machine is made from SUS304, a high-quality stainless steel material known for its strength, durability, and resistance to corrosion. This ensures that the machine can withstand heavy usage and harsh cleaning chemicals without compromising its performance.
The Spraying Cleaning Machine utilizes high pressure spraying to effectively remove dirt, oil, grease, and other contaminants from the surface of cylinder heads and engine parts. This method ensures a thorough and efficient cleaning process, leaving the parts spotless and ready for use.
The basket load-bearing capacity of the machine is 400KG, but it can be customized to meet the specific needs of your business. This allows you to clean larger or heavier parts without compromising the performance of the machine.
The basket rotation drive of the Spraying Cleaning Machine is powered by a 0.55kw motor, making it easy and convenient to operate. This ensures that the parts are evenly cleaned and eliminates the need for manual rotation, saving time and effort.
The Spraying Cleaning Machine is a highly efficient and durable industrial cleaning machine designed specifically for cylinder heads and engine parts. With its high pressure spraying, customizable load-bearing capacity, and convenient basket rotation drive, it is the perfect solution for businesses looking to improve their cleaning process and maintain the quality of their parts.
Technical Parameters:
| Product Name: | Spraying Cleaning Machine with Rotary Basket |
|---|---|
| Model: | JP-1500P |
| Cleaning Method: | High Pressure Spraying |
| Basket | 900mm |
| Work Space Height: | 850mm |
| Basket Load-bearing: | 400KG (can Be Customized) |
| Water Pump Power: | 3KW |
| Spray Pressure: | 3-5 Bar Adjustable |
| Basket Rotation Drive: | Motor/0.37KW |
| Sub-Tank Capacity: | 200L |
| Rotating Speed: | 10~50R/MIN adjustable |
| Spraying Cleaning Machine With Rotating Basket | ||||||||||
| Model | Basket Diameter | Work Space Height | Cavity Material | Basket Load-bearing |
Basket Rotation Drive |
Rotating Speed (R/MIN) |
Sub-Tank Capacity | Heating Power | Water Pump Power | Spray Pressure (Bar) |
| JP-0500ZP | 500mm | 300mm | SUS304/1.5MM | 50kg | Spray drives rotation | - | 40L | 3KW | 0.55KW | 2.5 |
| JP-0600ZP | 600mm | 350mm | SUS304/1.5MM | 50kg | Spray drives rotation | - | 65L | 3KW | 0.55KW | 2.5 |
| JP-0500P | 500mm | 300mm | SUS304/1.5MM | 80kg | Motor/0.15kw | 10~50 | 50L | 3KW | 0.55KW | 2.5 |
| JP-0600P | 600mm | 350mm | SUS304/1.5MM | 80kg | Motor/0.15kw | 10~50 | 70L | 3KW | 0.55KW | 2.5～3 |
| JP-0700P | 700mm | 350mm | SUS304/1.5MM | 80kg | Motor/0.15kw | 10~50 | 85L | 3KW | 0.75KW | 2.5～3 |
| JP-0800P | 800mm | 500mm | SUS304/2.0MM | 250kg | Motor/0.15kw | 10~50 | 100L | 6KW | 0.75KW | 2.5～3 |
| JP-0900P | 900mm | 500mm | SUS304/2.0MM | 250kg | Motor/0.15kw | 10~50 | 130L | 6KW | 1.5KW | 2.5～3 |
| JP-1000P | 1000mm | 720mm | SUS304/2.0MM | 250kg | Motor/0.37kw | 10~50 | 145L | 6KW | 2.2KW | 3～5 |
| JP-1200P | 1200mm | 730mm | SUS304/2.0MM | 350kg | Motor/0.37kw | 10~50 | 160L | 9KW | 2.2KW | 3～5 |
| JP-1500P | 1500mm | 850mm | SUS304/2.0MM | 400kg | Motor/0.55kw | 10~50 | 200L | 9KW | 3KW | 3～5 |
| JP-2000P | 2000mm | 1000mm | SUS304/2.0MM | 600kg | Motor/0.75kw | 10~50 | 450L | 12KW | 3KW | 3～5 |
Highly equipped with automatic switch cover and PLC control
Note: Customization of high-pressure rotary spray cleaning machines of different sizes is supported. Please consult customer service for details.
Advantages of the Rotary Basket High Pressure Water Spraying Cleaning Machine
One-touch operation, adjustable spray pressure
720° cleaning without dead ends
Large cleaning batches, saving labor
Liquid real-time circulation filtration system to improve liquid utilization efficiency
Equipment has low energy consumption and low noise
The high-pressure spray cleaning machine can clean workpieces in batches with high efficiency and uniform effect.
Strong controllability and low cost
Operating procedures of Rotary Basket High Pressure Water Spraying Cleaning Machine
Open the upper cover and place the workpiece on the turntable;
Set spray cleaning time;
Turn on the device start button, and the device will enter the automatic cleaning state. After cleaning, the device will automatically
Stop moving;
Open the upper cover and manually unload the material
The Spraying Cleaning Machine is suitable for a variety of industrial cleaning applications, including but not limited to
- Cylinder block cleaning machine for automotive and heavy-duty engines
- Cleaning of metal parts in manufacturing plants
- Degreasing and cleaning of industrial equipment and machinery
- Removal of contaminants from metal surfaces in machining processes
- Cleaning of engine components in automotive and aerospace industries
- Surface preparation before painting or coating
- Cleaning of parts in the food, pharmaceutical, and chemical industries
- And many more industrial cleaning applications
