Product Details:
|
| Model: | JP-2108GH | Tank Volume: | 540L |
|---|---|---|---|
| Ultrasonic Power: | 5400W | Heating Power: | 18000W |
| Frequency: | 40KHz/28KHz | Internal Tank Size: | 1000X900X600mm (L*W*H) |
| Filter Cycle System: | 1 Set | Gross Weight: | 800KG |
| High Light: | 40kHz Sonic Wave Ultrasonic Cleaner,DPF PDF Sonic Wave Ultrasonic Cleaner,140 Gallon Ultrasonic Engine Cleaner |
||
Ultrasonic Cleaning Machine for Resin with Hot Air Dryer
|
Model
|
Tank size
|
Capacity
|
Transducer
|
Ultrasonic power
|
Heating power
|
Frequency
|
Generator
|
|
(cm)
|
(L)
|
(pcs)
|
(W)
|
(W)
|
(kHz)
|
(set)
|
|
|
JP-2012GH
|
50*30*25
|
38
|
12
|
600
|
1500
|
28/40
|
1
|
|
JP-2018GH
|
50*35*30
|
53
|
18
|
900
|
1500
|
28/40
|
1
|
|
JP-2024GH
|
55*40*35
|
77
|
24
|
1200
|
3000
|
28/40
|
1
|
|
JP-2030GH
|
55*45*40
|
99
|
30
|
1500
|
3000
|
28/40
|
1
|
|
JP-2036GH
|
60*50*45
|
135
|
36
|
1800
|
4500
|
28/40
|
1
|
|
JP-2048GH
|
70*50*50
|
175
|
48
|
2400
|
6000
|
28/40
|
2
|
|
JP-2060GH
|
80*60*55
|
264
|
60
|
3000
|
6000
|
28/40
|
2
|
|
JP-2072GH
|
100*60*60
|
360
|
72
|
3600
|
9000
|
28/40
|
2
|
|
JP-2108GH
|
100*90*60
|
540
|
108
|
5400
|
18000
|
28/40
|
3
|
|
JP-2144GH
|
120*100*80
|
960
|
144
|
7200
|
24000
|
28/40
|
4
|
|
No
|
|||
|
1
|
Model
|
JP-2108GH (Ultrasonic cleaning + Filter+ hot air drying)
|
|
|
2
|
1st Tank
|
Function
|
Ultrasonic cleaning + Filter+ Hot water cleaning
|
|
Ultrasonic Frequency
|
28/40kHz (other frequency can be customized)
|
||
|
Tank Material
|
SUS 304 (SUS 316 can be customized)
|
||
|
Inner tank dimension
|
1000*900*600mm
|
||
|
Tank Capacity
|
540L
|
||
|
Transducer
|
108pcs
|
||
|
Ultrasonic Power
|
5400W
|
||
|
Heating Power
|
18000W
|
||
|
Time setting of Ultrasonic
|
0~99 hours
|
||
|
Temperature setting
|
Room temperature ~ 95°C adjustable
|
||
|
Thickness of tank
|
2mm
|
||
|
Drain value
|
Yes, in the right side of machine
|
||
|
Water inlet/outlet
|
Yes
|
||
|
Filter
|
1 set, connect with 1st tank
|
||
|
Generator
|
1 set
|
||
|
Lid
|
Yes, hinged with machine body, with gasket
|
||
|
Basket load
|
300KG
|
||
|
3
|
2nd tank
|
Function
|
Hot air drying tank
|
|
Inner tank dimension
|
1000*900*600mm
|
||
|
Turbines power
|
750W
|
||
|
Dryer power
|
3000W
|
||
|
4
|
Packing
|
Overall size
|
260*170*130cm
|
|
Packing size
|
270*180*150cm
|
||
|
Packing detail
|
By wooden case(No logs, free of fumigation)
|
||
|
5
|
Warranty
|
1 year warranty for spare parts, all life technical support
|
|
|
6
|
Certificate
|
CE, RoHS; FCC, REACH
|
|
|
7
|
Production time
|
5 days if there is stock; 20 days if there is no stock
|
|
Commercial hardware machinery ultrasonic cleaning machines are suitable for cleaning applications such as optics, machinery, auto maintenance, electronics, jewelry, jade, hardware parts, assembly parts, electronic tools, circuit boards, etc.
It has a good effect on the slits, grooves, deep holes, blind holes, surface cleaning, degreasing, rust removal, and oxide removal of cleaning objects.
In addition to the working conditions of ultrasonic cleaning application, the power switching T-type is mainly used for cleaning of special equipment in agronomy, food, cosmetics and other industries, as well as extraction and emulsification of ingredients.
Machinery industry: removal of anti-rust grease, cleaning of measuring tools, degreasing and derusting of mechanical parts, cleaning of engines, carburetors and auto parts, dredging and cleaning of filters and screens.
Surface treatment industry: degreasing and rust removal before electroplating, cleaning before ion plating, phosphating treatment, carbon deposit removal, oxide scale removal, polishing paste removal, surface activation treatment of metal workpieces.
Instrumentation industry: high cleanliness of precision parts, deep cleaning before assembly.
Electronics industry: cleaning of mechanical and electronic parts such as rosin, solder spots, and high-voltage contacts on printed circuit boards.
Medical industry: cleaning of medical equipment and utensils.
Semiconductor industry: high cleanliness cleaning of semiconductor wafers.
Watch and jewelry industry: cleaning sludge, dust, oxide layer, polishing paste, etc.
Biochemical industry: cleaning and descaling of laboratory utensils; sample pretreatment.
Optical industry: degreasing, sweating and dust removal of optical devices.
Textile printing and dyeing industry: cleaning textile spindles, spinnerets, etc.
Petrochemical industry: cleaning and dredging of metal filter screens, cleaning of chemical containers, exchangers, etc.
Ultrasonic cleaning of other hard workpieces and chemical cleaning agents to improve cleaning efficiency and improve cleanliness.
Working Principle:
The principle of the ultrasonic cleaning machine is mainly to convert the sound energy of the power ultrasonic frequency source into mechanical vibration through the transducer, and to irradiate the ultrasonic wave into the cleaning liquid in the groove through the cleaning tank wall. Due to the radiation of the ultrasonic waves, the microbubbles in the liquid in the tank can be kept vibrated by the action of the sound waves. The adsorption of the dirt and the surface of the cleaning member is destroyed, causing fatigue damage of the dirt layer to be rejected, and the vibration of the gas type bubble scrubs the solid surface.
Cleaning Effect show:
