1000L Semi-Automatic Ultrasonic Cleaner 3600W 28kHz

1000L Semi-Automatic Ultrasonic Cleaner 3600W 28kHz
1000L Semi-Automatic Ultrasonic Cleaner 3600W 28kHz 1000L Semi-Automatic Ultrasonic Cleaner 3600W 28kHz 1000L Semi-Automatic Ultrasonic Cleaner 3600W 28kHz 1000L Semi-Automatic Ultrasonic Cleaner 3600W 28kHz 1000L Semi-Automatic Ultrasonic Cleaner 3600W 28kHz 1000L Semi-Automatic Ultrasonic Cleaner 3600W 28kHz

Large Image :  1000L Semi-Automatic Ultrasonic Cleaner 3600W 28kHz

Product Details:
Brand Name: Skymen
Certification: CE
Document: Product Brochure PDF
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 4300

1000L Semi-Automatic Ultrasonic Cleaner 3600W 28kHz

Description
Model Number: JTS-11444 Automation Level: Semi-automatic
Cleaning Precision: General Industrial Cleaning Control Type: Artificial
Cleaning Principle: Physical Cleaning Frequency: 28kHz
Tank Size: 1000X600X600mm Power: 3600W
Max Capacity: 1000L Construction Case: SUS 304
Construction Tank: SUS 304 / 316L Max Heating Temp: 20~80C ADJUSTABLE
Heating Power: 9KW Timer: 0~30min Adjustable
Drain Valve: ¾"
Highlight:

1000L ultrasonic cleaner semi-automatic

,

industrial ultrasonic cleaner 3600W

,

28kHz ultrasonic cleaner with warranty

Large Size 1000L Electroplate Ultrasonic Cleaning Machine

This industrial ultrasonic cleaner is designed for large-scale cleaning applications, ideal for condenser/radiator/cooler/engine/filter/heat exchangers and various automotive parts.

Applications
  • Cleans and degreases engine blocks, oil filters, coolers, nozzles, wheels, and other automotive components
  • Effectively removes rust, carbon, paint, heavy oil, agricultural chemicals, and other tough contaminants
  • Safe for parts with no damage to components inside the tank
  • Custom tank dimensions and transducer configurations available
Multi-Stage Cleaning Process
  • First tank: Ultrasonic cleaning
  • Second tank: Rinsing
  • Third tank: Drying
1000L Semi-Automatic Ultrasonic Cleaner 3600W 28kHz 0
Skymen JTS Series Specifications
Model No. JTS-1030 JTS-1036 JTS-1060 JTS-1072 JTS-1108 JTS-1144
Tank Dimension (mm) 500x406x500 500x460x550 700x650x650 1000x600x600 1000x900x600 1200x1000x800
Overall Dimension (mm) 680x586x850 680x640x900 900x850x1000 1200x800x950 1240x1140x950 1440x1240x1150
Max. Capacity 101L 126L 295L 360L 540L 960L
Construction Case SUS 304 (Mirror shining image available)
Construction Tank SUS 304 / 316L
Ultrasonic Power (Max.) 1500W 1800W 3000W 3600W 5400W 7200W
Ultrasonic Frequency 28kHz/40kHz/68kHz/80kHz/120kHz
Max. Heating Temp. 20~80°C Adjustable
Heating Power 3KW 4.5KW 6KW 9KW 12KW 24KW
Timer 0~30min adjustable
Drain ¾" Valve
Lid & Basket Take-off/strut lid; SUS 304
Features Multi-direction castors with brake; 1 year warranty
Optional Filtration system (pump, SUS filter, oil catch can)
System Features
  • Replaceable transducer box and generator system
  • Flexible mounting options (immersible, side-mounted, or bottom-mounted)
  • Custom tank dimensions and transducer configurations available
  • Optional stainless steel basket
1000L Semi-Automatic Ultrasonic Cleaner 3600W 28kHz 1 1000L Semi-Automatic Ultrasonic Cleaner 3600W 28kHz 2
Benefits of Ultrasonic Cleaning

Ultrasonic cleaning has been proven to be the most efficient method for removing contaminants from both visible and invisible surfaces, including holes and cracks. If an item can be cleaned with liquid, ultrasonic cleaning makes the process faster and more thorough.

Why Choose Skymen Ultrasonic Cleaners?
  • Specially designed for industrial cleaning applications
  • Fast, efficient cleaning in minutes
  • 15 years of engineering expertise in every machine
  • 1-year warranty included
  • Free technical support and advice
  • Custom branding options available
  • Trial orders welcome (MOQ: 1 piece)
About Skymen Cleaning Equipment

Skymen Cleaning Equipment Shenzhen Co., Ltd. has specialized in ultrasonic cleaning technology for over 9 years. We offer comprehensive R&D, production, and sales services with a focus on high-quality products and excellent after-sales support.

Our engineering team can design both standard and custom ultrasonic cleaning solutions to meet your specific requirements. We welcome factory visits and business consultations.

Frequently Asked Questions
What frequency is better for my parts?

Frequency selection depends on the type of contaminants. 28kHz is stronger and better for automotive parts (oils, grease), while 40kHz is better for PCBs and electronic components. Higher precision items require higher frequencies.

Can ultrasonic cleaning damage parts?

Despite the powerful cleaning action, the process is safe and won't damage properly cleaned items.

What cleaning solution should I use?

Various specialized formulas are available for different applications. Proper selection is crucial for effective cleaning and to prevent reactions with workpieces.

Is rinsing necessary after cleaning cycles?

Rinsing is recommended to remove chemical residues. This can be done in the ultrasonic cleaner, a clean water bath, or with distilled/deionized water.
