Product Details:
|
| Model: | JTS-3030PH | Ultrasonic Power: | 1500W*2 |
|---|---|---|---|
| Transducers: | 30 Pcs In 1st Tank, 30 Pcs In 2nd Tank | Heating Power: | 3000W *2 |
| Frequency: | 40KHZ | ||
| High Light: | Industrial PCB Sonic Cleaning Machine,Sonic Industrial Washing Machine 100L,BSCI Sonic Cleaning Machine 40Khz |
||
How does Ultrasonic Cleaner work?
How Ultraosnic Cleaner Work?
Cavitation, the collapse of millions of tiny bubbles created by ultrasonic vibrations, releases high energy and enormous cleaning power.
This cleaningaction gently and thoroughly removes dirt, oil, and contaminants from every surface in contact with the cleaning fluid.
Because the liquid can penetrateinto very small crevices, ultrasonic cleaning can clean intricate items that cannot be cleaned by hand.
Parameters
| Model |
JTS-3030PH |
| 1st Tank Volume | 100L Ultrasonic Cleaning tank with ultrasonic,heating |
| 2nd Tank Volume | 100L Ultrasonic Rinsng tank |
| 3rd Tank Volume | 100L Drying tank |
| 1st tank size5 | 500X450X400mm |
| 2nd tank size | 550X450X400mm |
| 3rd Tank size | 550X450X400mm |
| Transducers | 30pcs in 1st tank; 30pcs in 2nd tank |
| Ultrasonic Power | 1500W*2 |
| Heating Power of Ultrasonic tank | 3000W*2 |
| Heating Power of Drying tank | 750W |
| Frenquency | 28KHz/40KHz |
| Drying System | 1 set |
| Unit size | 2460*1310*1050mm |
| Packing size | 2520*1370*1170mm |
| Timer | 0~99 hours adjustable |
| Heater | Room temperature~99℃ adjustable |
| Material | SUS 304 default, can be SUS 316 |
| Power Supply | AC 220V 3 phase ; AC 380V 3 phase |
| N.W. | 370G |
| G.W. | 400KG Wrapped by film in wooden case |
| Lead time | 18 working days |
| Warranty | 1 year warranty period, technique support all time |
| Certificates | CE, RoHS, FCC, SGS |
| Advantage | Filter the dirty water; keep the water clear in tank; lower the frequency of changing water |
