Product Details:
|
| Model: | JTS-3048GPH | First Tank Volume: | 77L |
|---|---|---|---|
| First Tank Size: | 550X400X350mm | Transducers: | 24pcs In 1st Tank; 24pcs In 2nd Tank |
| Ultrasonic Power: | 1200W*2 | Heating Power: | 3000W*2 |
| Function: | Ultrasonic Clean+rinsing+filter+drying | Frequency: | 28/40KHz |
| High Light: | ultrasonic cleaning device,ultrasonic washing machine |
||
3 Bins Ultrasonic Cleaner for Haemostatic forceps with Rinsing, Filter, Dryer 77L
Specification
| Model | JTS-3048GPH |
| 1st Tank Volume | 77L Ultrasonic Cleaning tank with filtration cycle system |
| 2nd Tank Volume | 77L Ultrasonic Rinsng tank |
| 3rd Tank Volume | 77L Drying tank |
| 1st tank size | 550X400X350mm |
| 2nd tank size | 550X400X350mm |
| 3rd Tank size | 550X400X350mm |
| Transducers | 24pcs in 1st tank; 24pcs in 2nd tank |
| Ultrasonic Power | 1200W*2 |
| Heating Power of Ultrasonic tank | 3000W*2 |
| Heating Power of Drying tank | 750W |
| Frenquency | 28KHz/40KHz |
| Drying System | 1 set |
| Unit size | 2215*1050*950mm |
| Packing size | 2275*1110*1070mm |
| Timer | 0~99 minutes adjustable |
| Heater | Room temperature~99℃ adjustable |
| Material | SUS 304 default, can be SUS 316 |
| Power Supply | AC 220V 3 phase ; AC 380V 3 phase |
| N.W. | 310G |
| G.W. |
350KG Wrapped by film in wooden case |
| Lead time | 18 working days |
| Warranty | 1 year warranty period, technique support all time |
| Certificates | CE, RoHS, FCC, SGS |
| Advantage | Filter the dirty water; keep the water clear in tank; lower the frequency of changing water |
Principle
The principle of the ultrasonic cleaning machine is mainly to convert the sound energy of the power ultrasonic frequency source into mechanical vibration through the transducer, and to irradiate the ultrasonic wave into the cleaning liquid in the groove through the cleaning tank wall. Due to the radiation of the ultrasonic waves, the microbubbles in the liquid in the tank can be kept vibrated by the action of the sound waves. The adsorption of the dirt and the surface of the cleaning member is destroyed, causing fatigue damage of the dirt layer to be rejected, and the vibration of the gas type bubble scrubs the solid surface.
Same series with different size for your choice:
| Model | Size of every tank | Tank Volume | Ultrasonic Power |
Heating Power of Ultrasonic tank | Heating Power of drying tank | Transducer |
| L*W*H (mm) | (L) | (W) | (W) | 750W | (pcs) | |
| JP-2024GPH | 500X300X250 | 38L*3 | 600W | 1500W*2 | 750W | 24pcs |
| JP-2036GPH | 500X350X300 | 53L*3 | 900W | 1500W*2 | 750W | 36pcs |
| JP-2048GPH | 550X400X350 | 77L*3 | 1200W | 3000W*2 | 750W | 48pcs |
| JP-2060GPH | 550X450X400 | 99L*3 | 1500W | 3000W*2 | 750W | 60pcs |
| JP-2072GPH | 600X500X450 | 135L*3 | 1800W | 4500W*2 | 750W | 72pcs |
| JP-2096GPH | 700X500X500 | 175L*3 | 2400W | 6000W*2 | 750W | 96pcs |
| JP-2120GPH | 800X600X550 | 264L*3 | 3000W | 6000W*2 | 750W | 120pcs |
| JP-2144GPH | 1000X600X600 |
360L*3 |
3600W | 9000W*2 | 750W | 144pcs |
| JP-2216GPH | 1000X900X600 | 540L*3 | 5400W | 18000W*2 | 1100W | 216pcs |
| JP-2288GPH | 12000*1000*800 | 960L*3 | 7200W | 24000W*2 | 1500W | 288pcs |
Images:
Clean effect:
What benefit can i get?
● Labor cost is substantially reduced
● Increase the Parts life
● Reduced Parts damage from cleaning
● Reduced wastages
● Environmentally friendly
● Easy to maintain system
● MOSFET / IGBT Base technology save the power
● Heater with thermostatically control increase cleaning effect
● Rust free stainless steel housing, easy to clean
● Free Lid & basket as per customer need
History:
Skymen Cleaning Equipment Shenzhen Co., Ltd., was founded in 2007,which follows the brand development strategy of “based in Shenzhen, radiating throughout the country, expanding overseas”.
Skymen also owns a professional R&D team to keep the pace with international ultrasonic technology. A passionate and young sales team sell to the world through different channels.
